| 料号 | 频率(MHZ) | 工作温度 | 负载电容 | 精度 |
| ABM3-15.000MHz-B4Y-T | 15MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-22.1184MHz-D2Y-T | 22.1184MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-13.000MHz-B4Y-T | 13MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-24.576MHz-B4Y-T | 24.576MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-50.000MHz-D2Y-F-T | 50MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-13.52313MHz-10-B4Y-T | 13.52313MHz | 20°C+70°C | 10PF | ±30PPM |
| ABM3-11.0592MHz-D2Y-T | 11.0592MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-8.000MHz-B4Y-T | 8MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-24.576MHz-D2Y-T | 24.576MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-16.000MHz-D2Y-T | 16MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-12.000MHz-D2Y-T | 12MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-24.576MHz-B2-T | 24.576MHz | 20°C+70°C | 18PF | ±20PPM |
| ABM3-33.000MHz-B2-T | 33MHz | 20°C+70°C | 18PF | ±20PPM |
| ABM3-33.000MHz-D2Y-T | 33MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-40.000MHz-B2-T | 40MHz | 20°C+70°C | 18PF | ±20PPM |
| ABM3-14.31818MHz-B2-T | 14.31818MHz | 20°C+70°C | 18PF | ±20PPM |
| ABM3-10.000MHz-B4Y-T | 10MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-13.560MHz-B4Y-T | 13.56MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-27.000MHz-B4Y-T | 27MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-33.000MHz-B4Y-T | 33MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-48.000MHz-B4Y-T | 48MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-29.4912MHz-B4Y-T | 29.4912MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-19.6608MHz-B4Y-T | 19.6608MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-24.000MHz-B4Y-T | 24MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-48.000MHz-B2-T | 48MHz | 20°C+70°C | 18PF | ±20PPM |
| ABM3-14.31818MHz-B4Y-T | 14.31818MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-19.6608MHz-D2Y-T | 19.6608MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-9.8304MHz-D2Y-T | 9.8304MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-30.000MHz-B4Y-T | 30MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-32.000MHz-B4Y-T | 32MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-20.000MHz-B4Y-T | 20MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-11.0592MHz-B4Y-T | 11.0592MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-22.1184MHz-B4Y-T | 22.1184MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-40.000MHz-B4Y-T | 40MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-18.432MHz-B4Y-T | 18.432MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-12.000MHz-B4Y-T | 12MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-25.000MHz-B4Y-T | 25MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-30.000MHz-B2-T | 30MHz | 20°C+70°C | 18PF | ±20PPM |
| ABM3-26.000MHz-B4Y-T | 26MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-14.7456MHz-B4Y-T | 14.7456MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-16.000MHz-B4Y-T | 16MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-11.2896MHz-D2Y-T | 11.2896MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-29.4912MHz-B2-T | 29.4912MHz | 20°C+70°C | 18PF | ±20PPM |
| ABM3-27.000MHz-B2-T | 27MHz | 20°C+70°C | 18PF | ±20PPM |
| ABM3-28.6363MHz-B2-T | 28.6363MHz | 20°C+70°C | 18PF | ±20PPM |
| ABM3-14.7456MHz-D2Y-T | 14.7456MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-32.000MHz-D2Y-T | 32MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-18.432MHz-B2-T | 18.432MHz | 20°C+70°C | 18PF | ±20PPM |
| ABM3-18.432MHz-D2Y-T | 18.432MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-10.0000MHz-D2Y-T | 10MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-8.192MHz-B4Y-T | 8.192MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-12.288MHz-B4Y-T | 12.288MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-27.000MHz-D2Y-T | 27MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-20.000MHz-D2Y-T | 20MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-25.000MHz-B2-T | 25MHz | 20°C+70°C | 18PF | ±20PPM |
| ABM3-13.560MHz-B2-T | 13.56MHz | 20°C+70°C | 18PF | ±20PPM |
| ABM3-30.000MHz-D2Y-T | 30MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-16.384MHz-B4Y-T | 16.384MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-9.8304MHz-B4Y-T | 9.8304MHz | 20°C+70°C | 18PF | ±30PPM |
| ABM3-40.000MHz-D2Y-F-T | 40MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-25.000MHz-D2Y-T | 25MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-12.288MHz-D2Y-T | 12.288MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-24.000MHz-D2Y-T | 24MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-8.000MHz-D2Y-T | 8MHz | 40°C+85°C | 18PF | ±20PPM |
| ABM3-12.000MHz-B2-T | 12MHz | 20°C+70°C | 18PF | ±20PPM |
| ABM3-20.000MHz-B2-T | 20MHz | 20°C+70°C | 18PF | ±20PPM |
| ABM3-24.000MHz-B2-T | 24MHz | 20°C+70°C | 18PF | ±20PPM |
| ABM3-16.000MHz-B2-T | 16MHz | 20°C+70°C | 18PF | ±20PPM |
| ABM3-14.31818MHz-D2Y-T | 14.31818MHz | 40°C+85°C | 18PF | ±20PPM |
