| 料号 | 频率(MHZ) | 工作温度 | 负载电容 | 精度 |
| ABM11AIG-25.000MHz-6-2-T | 25MHz | 40°C+125°C | 6PF | ±100PPM |
| ABM11AIG-24.576MHz-4Z-T | 24.576MHz | 40°C+125°C | 10PF | ±30PPM |
| ABM11AIG-25.000MHz-4Z-T | 25MHz | 40°C+125°C | 10PF | ±30PPM |
| ABM11AIG-19.200MHz-4Z-T | 19.2MHz | 40°C+125°C | 10PF | ±30PPM |
| ABM11AIG-24.000MHz-4Z-T | 24MHz | 40°C+125°C | 10PF | ±30PPM |
| ABM11AIG-20.000MHz-4Z-T | 20MHz | 40°C+125°C | 10PF | ±30PPM |
| ABM11AIG-40.000MHz-4Z-T | 40MHz | 40°C+125°C | 10PF | ±30PPM |
| ABM11AIG-26.000MHz-1-T | 26MHz | 40°C+125°C | 10PF | ±10PPM |
| ABM11AIG-24.000MHz-2Z-T | 24MHz | 40°C+125°C | 10PF | ±20PPM |
| ABM11AIG-32.000MHz-4Z-T | 32MHz | 40°C+125°C | 10PF | ±30PPM |
| ABM11AIG-48.000MHz-1-T | 48MHz | 40°C+125°C | 10PF | ±10PPM |
| ABM11AIG-27.000MHz-1-T | 27MHz | 40°C+125°C | 10PF | ±10PPM |
| ABM11AIG-48.000MHz-4-1Z-T | 48MHz | 40°C+125°C | 4PF | ±10PPM |
| ABM11AIG-32.000MHz-4-1Z-T | 32MHz | 40°C+125°C | 4PF | ±10PPM |
| ABM11AIG-27.000MHz-4-1Z-T | 27MHz | 40°C+125°C | 4PF | ±10PPM |
| ABM11AIG-48.000MHz-7-4Z-T | 48MHz | 40°C+125°C | 7PF | ±30PPM |
| ABM11AIG-24.576MHz-1Z-T | 24.576MHz | 40°C+125°C | 10PF | ±10PPM |
| ABM11AIG-32.000MHz-6-Z-T | 32MHz | 40°C+125°C | 6PF | ±50PPM |
| ABM11AIG-20.000MHz-8-1Z-T | 20MHz | 40°C+125°C | 8PF | ±10PPM |
| ABM11AIG-24.000MHz-3Z-T | 24MHz | 40°C+125°C | 10PF | ±25PPM |
| ABM11AIG-48.000MHz-1Z-T | 48MHz | 40°C+125°C | 10PF | ±10PPM |
| ABM11AIG-50.000MHz-8-1Z-T | 50MHz | 40°C+125°C | 8PF | ±10PPM |
| ABM11AIG-25.000MHz-4-1F-T | 25MHz | 40°C+125°C | 4PF | ±10PPM |
| ABM11AIG-27.120MHz-3Z-T | 27.12MHz | 40°C+125°C | 10PF | ±25PPM |
| ABM11AIG-40.000MHz-4-1Z-T | 40MHz | 40°C+125°C | 4PF | ±10PPM |
| ABM11-44.000MHz-D2X-T | 44MHz | 40°C+85°C | 10PF | ±20PPM |
| ABM11-36.000MHz-B7G-T | 36MHz | 20°C+70°C | 10PF | ±15PPM |
| ABM11-44.000MHz-B7G-T | 44MHz | 20°C+70°C | 10PF | ±15PPM |
| ABM11-16.000MHz-12-N1G-T | 16MHz | 30°C+85°C | 12PF | ±10PPM |
| ABM11-32.000MHz-B7G-T | 32MHz | 20°C+70°C | 10PF | ±15PPM |
| ABM11-30.000MHz-D2X-T | 30MHz | 40°C+85°C | 10PF | ±20PPM |
| ABM11-20.000MHz-B7G-T | 20MHz | 20°C+70°C | 10PF | ±15PPM |
| ABM11-27.000MHz-B7G-T | 27MHz | 20°C+70°C | 10PF | ±15PPM |
| ABM11-28.63636MHz-B7G-T | 28.63636MHz | 20°C+70°C | 10PF | ±15PPM |
| ABM11-36.000MHz-D2X-T | 36MHz | 40°C+85°C | 10PF | ±20PPM |
| ABM11-30.000MHz-B7G-T | 30MHz | 20°C+70°C | 10PF | ±15PPM |
| ABM11-25.000MHz-D7X-T | 25MHz | 40°C+85°C | 10PF | ±15PPM |
| ABM11-25.000MHz-B7G-T | 25MHz | 20°C+70°C | 10PF | ±15PPM |
| ABM11-26.000MHz-B7G-T | 26MHz | 20°C+70°C | 10PF | ±15PPM |
| ABM11-16.000MHz-9-B1U-T | 16MHz | 20°C+70°C | 9PF | ±10PPM |
| ABM11-24.000MHz-B7G-T | 24MHz | 20°C+70°C | 10PF | ±15PPM |
| ABM11-28.63636MHz-D2X-T | 28.63636MHz | 40°C+85°C | 10PF | ±20PPM |
| ABM11-16.000MHz-B7G-T | 16MHz | 20°C+70°C | 10PF | ±15PPM |
| ABM11-24.000MHz-D2X-T | 24MHz | 40°C+85°C | 10PF | ±20PPM |
| ABM11-16.000MHz-D2X-T | 16MHz | 40°C+85°C | 10PF | ±20PPM |
| ABM11-20.000MHz-D2X-T | 20MHz | 40°C+85°C | 10PF | ±20PPM |
| ABM11-38.400MHz-B7G-T | 38.4MHz | 20°C+70°C | 10PF | ±15PPM |
| ABM11-40.000MHz-B7G-T | 40MHz | 20°C+70°C | 10PF | ±15PPM |
| ABM11-40.000MHz-D2X-T | 40MHz | 40°C+85°C | 10PF | ±20PPM |
| ABM11-27.000MHz-D2X-T | 27MHz | 40°C+85°C | 10PF | ±20PPM |
| ABM11-48.000MHz-D2X-T | 48MHz | 40°C+85°C | 10PF | ±20PPM |
| ABM11-32.000MHz-D2X-T | 32MHz | 40°C+85°C | 10PF | ±20PPM |
| ABM11-38.400MHz-D2X-T | 38.4MHz | 40°C+85°C | 10PF | ±20PPM |
| ABM11-48.000MHz-B7G-T | 48MHz | 20°C+70°C | 10PF | ±15PPM |
| ABM11-25.000MHz-D2X-T | 25MHz | 40°C+85°C | 10PF | ±20PPM |
| ABM11-26.000MHz-D2X-T | 26MHz | 40°C+85°C | 10PF | ±20PPM |
