| 料号 | 频率(MHZ) | 工作温度 | 频率稳定性 | 频率容差 | 负载电容 |
| CMR309T-50.000MABJ-UT | 50MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T49.152MABJTR | 49.152MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-27.000MABJ-UT | 27MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-40.000MABJ-UT | 40MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-14.31818MABJ-UT | 14.31818MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-48.000MABJ-UT | 48MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-22.1184MABJ-UT | 22.1184MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-24.000MABJ-UT | 24MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T12.000MABJTR | 12MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T5.000MABJTR | 5MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-7.3728MABJ-UT | 7.3728MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T27.000MABJTR | 27MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T48.000MABJTR | 48MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T6.000MABJTR | 6MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T24.576MABJTR | 24.576MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T11.0592MABJTR | 11.0592MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T16.000MABJTR | 16MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T18.432MABJTR | 18.432MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T40.000MABJTR | 40MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T14.31818MABJTR | 14.31818MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T4.096MABJTR | 4.096MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T4.800MABETR | 4.8MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 12pF |
| CMR309T22.1184MABJTR | 22.1184MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T24.000MABJTR | 24MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-5.000MABJ-UT | 5MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-8.000MABJ-UT | 8MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-12.000MABJ-UT | 12MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T8.000MABJTR | 8MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-4.9152MABJ-UT | 4.9152MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T10.000MABJTR | 10MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T50.000MABJTR | 50MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-16.000MABJ-UT | 16MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-16.384MABJ-UT | 16.384MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T9.8304MABJTR | 9.8304MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T16.384MABJTR | 16.384MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-6.000MABJ-UT | 6MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-24.576MABJ-UT | 24.576MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T7.3728MABJTR | 7.3728MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T32.000MABJTR | 32MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-10.000MABJ-UT | 10MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-12.288MABJ-UT | 12.288MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T12.288MABJTR | 12.288MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T4.9152MABJTR | 4.9152MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T60.000MABJTR | 60MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-18.432MABJ-UT | 18.432MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T66.666MABJTR | 66.666MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-4.096MABJ-UT | 4.096MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
| CMR309T-11.0592MABJ-UT | 11.0592MHz | -10°C ~ 60°C | ±50ppm | ±30ppm | 18pF |
